Ducati Single Parts List By WCBR |
This list of parts & part numbers has been compiled by WCBR over the many years we've raced these machines. A majority of the part numbers are genuine Ducati, while others may look like a Ducati #, they are really our part number. When ordering, please use part numbers when possible. Some items listed may require special ordering or fabricating, while others may be out of stock. Those listed NLS = No Longer Supplied (by the manufacturer). |
If you would like to print these parts list pages, and the Ducati Service Material elsewhere on this site, please feel free to do so. Please be aware that, like this web site, these pages are protected by Copyright 1992-2005 by WCB/WCBR. |
ENGINE: Top-End assembly. Part# Disc. Price 0603.92.120 Exhaust Valve, 36mm Std $49.21 0603.92.120T36 Exhaust Valve, 36mm Titan $130.00 0603.92.120T36.7 Ex Valve, 36x7mm Titan $130.00 0603.92.120T38 Exhaust Valve, 38mm Titan $130.00 0603.92.110 Intake Valve, 40mm Std $49.21 0603.92.110T40 Intake Valve, 40mm Titan $130.00 0603.92.110T40.7 In Valve, 40x7mm Titan $130.00 0603.92.110T41 Intake Valve, 41mm Titan $130.00 0603.92.110T42 Intake Valve, 42mm Titan $130.00 0603.92.390 Guide, Valve, Std $13.95 0603.92.395 Guide, Valve +.002 $13.95 0603.92.396 Guide, Valve +.009 $13.95 0603.92.390C Guide, Valve, Custom $26.00 0600.92.343 Collet, Valve 4-each $2.50-ea 0603.92.240 Seal, Valve 2-each $3.25-ea 7003RD Seal, Valve for custom guide $5.50-ea 0420-92-140 Valve Spring, Hairpin 4-ea $19.50-ea 607-D Coil Valve Spring kit, Titan $105.00 0601.92.170 Rocker Arm, solid $140.00 Labor Regrind Rocker Arm $ 79.00-ea 0600-92-170 Rocker Arm, adjustable $123.75 0400-92.250 Bushing, Rocker 2-ea $15.00-ea 0400.92.255 Bushing, Rocker +.005 $15.00-ea 0600.92.240 Shaft, Rocker $18.00 0400.70.120 Flat Shim, Rocker $00.40 0150.92.220 Spring Shim, Rocker $1.25 75120.1542 Bearing, Cam 2-each $12.00-ea 0602.29.010 Camshaft, Mk3 Red-1064 $262.00 0603.29.010 Camshaft, Mach-1 Gray-1965 $262.00 0601.29.010 Camshaft, SCR White $200.00 564-00R Cam, Racing, MegaCycle $272.00 564-x9 Cam, Racing, MegaCycle $272.00 563-00 Cam, Racing, Mega Desmo $328.00 0400.29.020 Key, cam/crank $00.95 0400.29.050 Nut-LH, cam/crank $5.00 0400.29.040 Locktab, cam/crank $1.00 73503.3380 Circlip, cam $1.00 0606.92.640 Cam Bearing Holder 250 $38.00 0600.92.640 Cam Bearing Holder 350 $38.00 0606.92.820 Rocker Cover $27.80 |
Part# Disc. Price 0400.49.013 Bolt, Head/Cyl 200/250 $11.00 0400.49.010 Bolt, Head/Cyl 350 $11.00 0400.49.013CM Bolt, Head/Cyl 250 Chr Molly POR 0400.49.010CM Bolt, Head/Cyl 350 Chr Molly POR 75243.1542 Bearing, Towershaft, Upper $12.00 Note: When ordering Racing Pistons please include CR & Valve Dia. Note: All piston's must be clayed and sized, then machined as required to suit engine prior to running. Note: NO RETURN on Special Order or Custom Made Racing Parts. 64-00012/1D 68mm Piston 200cc, Cast $65.00 0500.47.400V 67mm Piston 200cc, Racing POR 0500.47.500V 68mm Piston 200cc, Racing POR 0500.47.600V 69mm Piston 200cc, Racing POR MC74STD 74mm MC Piston, 250 $100.00 MC74+020 74+.020 MC Piston, 250 $100.00 0603.47.400V 74mm Piston 250cc, Racing POR 0603.47.500V 74+020 Piston 250cc, Racing POR 0603.47.600V 75mm Piston 250cc, Racing $120.00 0606.47.500V 76+020 Piston 350cc, Racing POR 0606.47.600V 77mm Piston 350cc, Racing POR 0606.47.700V 77+.020" Piston 350cc, Racing POR 0606.47.800V 78mm Piston 350cc, Racing POR 0615.47.400V 86mm Piston 450cc, Racing POR 0615.47.500V 86+020 Piston 450cc, Racing POR 0615.47.600V 87mm Piston 450cc, Racing POR 0615.47.700V 86+020 Piston 450cc, Racing POR 0615.47.800V 87mm Piston 450cc, Racing POR 0615.47.901V LS500 Piston 500cc, Racing POR 0615.47.902V +020 Piston 500cc, Racing POR 0615.47.903V +040 Piston 500cc, Racing POR Note: When ordering rings state Bore Size in MM 0500.47.400R 67mm Ring Set 200cc POR 0603.47.400VR 74-76mm Ring Set 250cc $55.00 0606.47.400VR 76-78mm Ring Set 350cc $55.00 0615.47.500R 86-88mm Ring Set 450cc POR 0615.47.901R LS500 Ring Set 500cc POR 0602.47.460TB Teflon Button x2, 250/350 std $4.90-ea 0602.47.460TB+ Teflon Button x2, Ύ dia $4.90-ea 0615.47.460TB Teflon Button x2, 450 std $5.20-ea 0615.47.901TB Teflon Button x3, 500 $5.20-ea Labor Pin fit; fit wrist pin to piston $6.00-ea 0602.47.450 Piston Pin, 250/350 $18.00 0602.47.456 Piston Pin, Oversize $18.00 0602.47.750 Piston Pin, Ύ $20.00 0615.47.456 Piston Pin, 450/500 POR 0400.47.290 Small-end Bushing 200-350 $16.00 0400.47.295 Small-end Bushing Oversize $16.00 0400.47.750SP Small-end Bushing Ύ ID POR 0602.47.460 Circlip, piston $1.25-ea 66-00009D Gasket Set, 250/350 NC/WC $28.00 0600.51.104 Gasket Set, 175-350NC, Gen $25.00 0250.51.204 Gasket Set, 160JR OHC $19.00 0400.51.105 Oil Seal Set, all NC 5-speed $11.00 16-00199 Allen Kit, All NC 200-350 $30.00 16-00220 Allen Kit, Primary $10.00 16-00221 Allen Kit, T/C & GB Covers $11.00 16-00222 Allen Kit, Crankcase $4.00 16-00223 Allen Kit, Cyl-Head all $13.00 0601.84.010 Exhaust Collar Nut $ 22.00 0400.84.023 Exhaust Header 200-350 $78.00 0601.84.021 Exhaust Pipe, Scrambler POR 0602.84.100R Megaphone, Replica $125.00 0602.84.101D Muffler, Dunstall Replica $ 55.00 |
